Price: ₹762 - ₹424.00
(as of Mar 12, 2025 18:17:37 UTC – Details)
Description:
Operating Voltage:3-12V
Portable Design: The Size Is As Same As Of The Identity Card Which Can Be Set Into Pocket
There Are 3 Column Of Each Side (Left And Right), And Each Column Has Its Test Point.
The Circular Light Circuit Of The Middle Was Consisted By 4017, Ne555 And Light-Emitting Diodes; It Can Work After Welding Successfully.
There Are Graduation And Pcb Lead Example For Measuring Components And Designing Pcb More Convenient.
Specification:
Material: Pcb Board
Size: Approx. 85.6Mm— 54Mm —1.6Mm(L—W—H)/ 3.37”—2.13”—0.06”
All The Components Showed On The Pictures Are Included In The Kit
Welding Operating Diagram And Circuit Of The Light Diagram Are Included
Package Includes:
1 — Smd Component Welding Practice Board Kit Set
All The Components Showed On The Pictures Are Included In The Kit And Welding Operating Diagram And Circuit Of The Light Diagram Are Included
Portable Design: The Size Is As Same As Of The Identity Card Which Can Be Set Into Pocket
There Are 3 Column Of Each Side (Left And Right), And Each Column Has Its Test Point
The Circular Light Circuit Of The Middle Was Consisted By 4017, Ne555 And Light-Emitting Diodes; It Can Work After Welding Successfully
There Are Graduation And Pcb Lead Example For Measuring Components And Designing Pcb More Convenient
